Place of Origin:
GERMANY
Brand Name:
KUKA
Certification:
CE
Model Number:
KR 500 R2830
Contact Us
The Application of a Heavy Duty 500kg Kuka Robot in Mechanical Processing and Polishing
KUKA milling robot making sculptures at the Babysburg studio
A KUKA KR QUANTEC ultra series milling robot makes sculptures with hard foam in Art Department Studio Babelsberg GmbH. In this process, the robot is used as a separately configurable machine tool, independently and automatically completing all work steps. In addition, CNC milling ensures the completion of precise three-dimensional operations.
KUKA robots polish and grind kitchen knives for the Taiwanese brand Atlantic Chef.
Due to the use of multiple KUKA robots, Atlantic Chef's kitchen knives can be accurately ground.
Company Product Supply
ABB robot
KUKA robot
Yaskawa robot
Fanuc robot
UR robot
Cobot
Guide rail
Cobot made in China
| Basic Data | Maximum payload |
| 611 kg | |
| Maximum reach | |
| 2826 mm | |
| Mounting position | |
| Floor | |
| Pose repeatability (ISO 9283) | |
| 0.08 mm | |
| Number of axes | |
| 6 | |
| Ambient temperature during operation | |
| 10 °C to 55 °C (283 K to 328 K) | |
| Ambient temperature during stor./transp. | |
| -40 °C to 60 °C (233 K to 333 K) | |
| Protection rating (IEC 60529) | |
| IP65 | |
| Prot. rating, in-line wrist (IEC 60529) | |
| IP65 | |
| Motion Range | A1 |
| ±185 ° | |
| A2 | |
| -130 ° / 20 ° | |
| A3 | |
| -100 ° / 144 ° | |
| A4 | |
| ±350 ° | |
| A5 | |
| ±120 ° | |
| A6 | |
| ±350 ° | |
| Field of application | Applying/Painting/Glueing/Assembly/ Cutting/ Separation/ Handling/ Laser Welding/ Machining/ Measuring/Inspection/ Palletizing/packaging/ Spot Welding |
