Application of high-precision linear guide rails in the machining field of aerospace
Definition and Structure of High Precision Linear Guideway
High precision linear guide rail refers to a mechanical component composed of linear motion bearings, linear guide rails, and sliders, used to achieve linear motion control of mechanical and electrical equipment such as machine tools, robots, semiconductor manufacturing equipment, etc. Its main characteristics are its advantages of high precision, high rigidity, and high reliability.
The main structure of high-precision linear guide rails includes two parts: first, linear motion bearings, including rolling bearings, sliding bearings, etc; The second is linear guide rail, including linear guide rail and linear guide rail. The linear guide rail and linear motion bearing are fixed by connecting pieces such as fixed bolts or steel balls, forming a high-precision linear motion control system.
The robots adapted to the guide rail include ABB IRB1200, IRB1410, IRB2600,IRB4600, IRB6700 and IRB7600 robots, KUKA's kr210, kr120, kr10, kr10, kr20, kr50 and kr70, FANUC M10, M20, m710, M1000 and M2000, Yaskawa GP7, GP8, GP12, GP25, AR2010, GP50, GP88, BA200l, GP255 PL900 and pl300.
About the company
Our guide rail has cooperated with many international well-known robot brands, such as ABB KUKA FANUC Yaskawa UR. The companies involved mainly include palletizing, loading and unloading. The load of the guide rail ranges from 500kg to 5000kg. The length of the guide rail is customized according to the needs of customers. We have made a case that an ABB IRB6700 robot corresponds to 20 CNC machines, and a 50m long guide rail completes the reciprocating motion, loading and unloading of the robot. The number of robots is greatly reduced and the integration cost is saved.
Our company also offers industrial robots at very favorable prices to place orders together at lower prices.
Welcome to Shanghai, China, to investigate our robots and rails!
Company Product Supply.
ABB robot
KUKA robot
Yaskawa robot
Fanuc robot
UR robot
Cobot
Guide rail
Cobot made in China
product details
| NO | Name | Brand/Specification |
| 1 | Track body | YOUNGYOU/W=700mm,H=350mm,L=As required by the buyer |
| 2 | Planetary reducer | SHIMPO Japan |
| 3 | linear guide rail | HIWIN TaiWan HGH45 |
| 4 | Slide block | HIWIN TaiWan HGH45 |
| 5 | Rack and pinion | China TaiWan YCC Helical gear |
| 6 | lubrication system | YOUNGYOU 1L |
| 7 | Dust cover | YOUNGYOU/Semi enclosed sheet metal type/Organ style |
| 8 | Hard limit elastic buffer | YOUNGYOU |
| 9 | Robot mounting plate | YOUNGYOU/1200*1000*30mm |
| 10 | Ground connecting plate | YOUNGYOU |
| 11 | Drag chain | Koduct/W=200mm,H=45mm,R250mm |
| 12 | Reducer connecting flange | YOUNGYOU |
| 13 | Servo motor | ①linkage Robot external axis |
| ②Non linkage servo motor | ||
| 14 | Adjusting bolt | M15 fine pitch thread |
| 15 | Limit sensor | Japan Omron |
