Place of Origin:
china
Brand Name:
youngyou
Certification:
CE
Model Number:
EW-02-L#T-05-B
Contact Us
video
Robot Linear Rail is a high-quality and reliable product with superior performance. It is made of metal alloy, which can bear a load of up to 1600kg, and its acceleration can range from 1.2 to 2.7m/s. It adopts ground installation with chemical bolts, and the repeatability is within ±0.02mm.
| Parameter | Value |
|---|---|
| Installation method | Ground Installation (using Chemical Bolts) |
| Material quality | Metal Alloy |
| Effective stroke | 1-99 M (1m Interval, Customizable For Special And Ultra Long Travel) |
| Repeatability | ±0.02 Mm |
| Number of robot installations | 3 Units |
| Acceleration | 1.2-2.7m/s |
| Running speed | 1.2-2.7m/s |
| Driving method | AC Servo Motor Drive |
| Equipment load | 1600kg |
Robot Linear Guide Rail from Youngyou is designed specifically for industrial robots. With the brand name of Youngyou and model number of EW-02-L#T-05-B, this Robot Linear Guide Rail is made in China and has CE certification. The minimum order quantity of this product is 1, and the price is counselling. The package of this product is Wooden Case/Carton and the delivery time is 6-8weeks. The installation method of this Robot Linear Guide Rail is Ground Installation (using Chemical Bolts) and the material quality is Metal Alloy, with the equipment load of 1600kg and repeatability of ±0.02 Mm. The effective stroke range of this Robot Linear Guide Rail is from 1-99 M (1m Interval, Customizable For Special And Ultra Long Travel).
Youngyou's Robot Linear Guide Rail EW-02-L#T-05-B is an advanced product designed for the robot industry. It features a maximum load capacity of 1600kg, an acceleration of 1.2-2.7m/s, and a running speed of 1.2-2.7m/s. It is made from metal alloy and has an effective stroke of 1-99 m (1m interval, customizable for special and ultra long travel). It is certified by CE and is available in a minimum order quantity of 1.
Our team of experienced engineers is available to provide technical support and service for your Robot Linear Rail product. We provide comprehensive instruction and installation services, as well as troubleshooting and repairs. Our support team is available 24/7 to provide assistance when needed. We also offer a wide range of replacement parts, such as motors, controllers, and sensors, to keep your Robot Linear Rail product running smoothly.
If you have any questions or need assistance with your Robot Linear Rail product, please don't hesitate to contact us. Our team is here to help and ensure that you get the most out of your product.
Robot linear rails are packaged in corrugated cardboard boxes for protection during transit. The box is marked with the product name, quantity, and other relevant information. The inner packaging material is a foam lining that also helps to protect the product from damage during shipping. The box should be sealed properly for delivery.
The shipping method will depend on the size and weight of the product. Smaller items can be shipped via parcel delivery, while larger items can be shipped via freight. All orders should be tracked and insured for proper delivery.
